Page #2672 background image
C613-50100-01 REV C Command Reference for x930 Series 2672
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
ALLIED TELESIS MANAGEMENT FRAMEWORK™ (AMF) COMMANDS
SHOW
ATMF TECH
NOTE: The show atmf tech command can produce very large output. For this reason
only the most significant terms are defined in this table.
Domain VLAN The VLAN assigned for traffic between Nodes of same domain (crosslink).
VLAN ID - In this example VLAN 4091 is configured as the domain VLAN.
Domain Subnet - the Subnet address used for this traffic.
Domain IP Address - the IP address allocated for this traffic.
Domain Mask - the Netmask used to create a subnet for this traffic 255.255.128.0
(= prefix /17)
Device Type Shows the Product Series Name.
ATMF Master Indicates the nodes membership of the core domain (membership is indicated
by Y)
SC Shows switch configuration:
C - Chassis (such as SBx8100 series)
•S - Stackable (VCS)
•N - Standalone
Parent A node that is connected to the present nodes uplink, i.e. one layer higher in the
hierarchy.
Node Depth Shows the number of nodes in path from the current node to the Core domain.
Table 59: Parameter definitions from the show atmf tech command (cont.)
Parameter Definition
