ETHERNET PROTECTION SWITCHED RING (EPSRING™) COMMANDS
SHOW
EPSR
NOTE:
Output:
superloop
topology
The following examples show the output display for superloop topology network.
NOTE:
Table 2: Example output from the show epsr command run on a master node
EPSR Information
------------------------------------------------------------
Name ........................ test4
Mode .......................... Master
Status ........................ Enabled
State ......................... Complete
Control Vlan .................. 4
Data VLAN(s) .................. 20
Interface Mode ................ Ports Only
Primary Port .................. port1.0.3
Primary Port Status ........... Forwarding 
Secondary Port ................ port1.0.4
Secondary Port Status ......... Forwarding 
Hello Time .................... 1 s
Failover Time ................. 2 s
Ring Flap Time ................ 0 s
Trap .......................... Enabled
Enhanced Recovery ............. Disabled
------------------------------------------------------------
Table 3: Example output from the show epsr command run on a Master Node
EPSR Information
------------------------------------------------------------
Name ........................ test4
Mode .......................... Master
Status ........................ Enabled
State ......................... Complete
Control Vlan .................. 4
Data VLAN(s) .................. 20
Interface Mode ................ Ports Only
Primary Port .................. port1.0.3
Status ...................... Forwarding (logically blocking)
Is On Common Segment ........ No
Blocking Control ............ Physical
Secondary Port ................ port1.0.4
Status ...................... Blocked
Is On Common Segment ........ No
Blocking Control ............ Physical
Hello Time .................... 1 s
Failover Time ................. 2 s
Ring Flap Time ................ 0 s
Trap .......................... Enabled
Enhanced Recovery ............. Disabled
SLP Priority .................. 12
------------------------------------------------------------
