C613-50100-01 REV C Command Reference for x930 Series 1405
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
BGP AND BGP4+ COMMANDS
SHOW
IP BGP NEIGHBORS (BGP ONLY)
Output Figure 28-13: Example output from show ip bgp neighbors 10.10.10.72
If available the following is shown:
•Session information
– Neighbor address, ASN information and if the link is external or
internal
– BGP version and status
– Neighbor capabilities for the BGP session
– Number of messages transmitted and received
• IPv4 unicast address family information
–BGP table version
– IPv4 Address Family dependent capabilities
– IPv4 Communities
– IPv4 Route filters for ingress and egress updates
– Number of announced and accepted IPv4 prefixes
• Connection information
– Connection counters
– Graceful restart timer
– Hop count to the peer
– Next hop information
– Local and external port numbers
awplus#show ip bgp neighbors 10.10.10.72
BGP neighbor is 10.10.10.72, remote AS 100, local AS 100, internal
link
Member of peer-group group1 for session parameters
BGP version 4, remote router ID 0.0.0.0
BGP state = Active
Last read , hold time is 90, keepalive interval is 30 seconds
Received 0 messages, 0 notifications, 0 in queue
Sent 0 messages, 0 notifications, 0 in queue
Route refresh request: received 0, sent 0
Minimum time between advertisement runs is 5 seconds
For address family: IPv4 Unicast
BGP table version 1, neighbor version 0
Index 1, Offset 0, Mask 0x2
group1 peer-group member
NEXT_HOP is always this router
0 accepted prefixes
0 announced prefixes
Connections established 0; dropped 0
Next connect timer due in 33 seconds
