C613-50100-01 REV C Command Reference for x930 Series 1641

AlliedWare Plus™ Operating System - Version 5.4.6-1.x

IGMP AND IGMP SNOOPING COMMANDS

SHOW

IP IGMP SNOOPING STATISTICS

Figure 31-7: Example output from the show ip igmp snooping statistics

command for a switch port

awplus#show ip igmp interface port1.0.1

IGMP information for port1.0.1

Maximum groups limit set: 10

Number of groups port belongs to: 0
