C613-50100-01 REV C Command Reference for x930 Series 1908
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
IPV4 SOFTWARE ACCESS CONTROL LIST (ACL) COMMANDS
(ACCESS-LIST EXTENDED ICMP FILTER)
Mode IPv4 Extended ACL Configuration
Default Any traffic controlled by a software ACL that does not explicitly match a filter is
denied.
Usage An ACL can be configured with multiple ACL filters using sequence numbers. If the
sequence number is omitted, the next available multiple of 10 will be used as the
sequence number for the new filter. A new ACL filter can be inserted into the
middle of an existing list by specifying the appropriate sequence number.
NOTE: The access control list being configured is selected by running the access-list
(extended numbered) command or the access-list extended (named) command, with
the required access control list number, or name - but with no further parameters
selected.
Software ACLs will deny access unless explicitly permitted by an ACL action.
Examples To add a new entry in access-list called my-list that will reject ICMP packets from
10.0.0.1 to 192.168.1.1, use the commands:
awplus# configure terminal
awplus(config)# access-list extended my-list
awplus(config-ip-ext-acl)# deny icmp 10.0.0.1/32 192.168.1.1/32
Use the following commands to add a new filter at sequence number 5 position of
the access-list called my-list. The filter will accept the ICMP type 8 packets from
10.1.1.0/24 network, to 192.168.1.0 network:
awplus# configure terminal
awplus(config)# access-list extended my-list
awplus(config-ip-ext-acl)# 5 permit icmp 10.1.1.0/24
192.168.1.0/24 icmp-type 8
icmp-type The ICMP type.
<icmp-value> The value of the ICMP
type.
log Log the results.
Parameter Description
