C613-50100-01 REV C Command Reference for x930 Series 2081
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
802.1X COMMANDS
SHOW
DOT1X INTERFACE
awplus#show dot1x statistics interface port1.0.6802.1X statistics
for interface port1.0.6
EAPOL Frames Rx: 5 - EAPOL Frames Tx: 16
EAPOL Start Frames Rx: 0 - EAPOL Logoff Frames Rx: 0
EAP Rsp/Id Frames Rx: 3 - EAP Response Frames Rx: 2
EAP Req/Id Frames Tx: 8 - EAP Request Frames Tx: 2
Invalid EAPOL Frames Rx: 0 - EAP Length Error Frames Rx: 0
EAPOL Last Frame Version Rx: 1 - EAPOL Last Frame
Src:00d0.59ab.7037
Table 42-1: Parameters in the output of show dot1x interface
Parameter Description
portEnabled Interface operational status (Up-true/down-false).
portControl Current control status of the port for 802.1X control.
portStatus 802.1X status of the port (authorized/unauthorized).
reAuthenticate Reauthentication enabled/disabled status on port.
reAuthPeriod Value holds meaning only if reauthentication is enabled.
abort Indicates that authentication should be aborted when set
to true.
fail Indicates failed authentication attempt when set to false.
start Indicates authentication should be started when set to
true.
timeout Indicates authentication attempt timed out when set to
true.
success Indicates authentication successful when set to true.
state Current 802.1X operational state of interface.
mode Configured 802.1X mode.
reAuthCount Reauthentication count.
quietperiod Time between reauthentication attempts.
reAuthMax Maximum reauthentication attempts.
BE Backend authentication state machine variables and
constants.
state State of the state machine.
reqCount Count of requests sent to server.
