ALLIED TELESIS MANAGEMENT FRAMEWORK™ (AMF) COMMANDS
SHOW
ATMF
Related
Commands
show atmf detail
Node Name The name assigned to a particular node.
Role The role configured for this AMF device, either Master or Member.
Current ATMF
Nodes
The count of AMF nodes in an AMF Network.
Node Address An address used to access a remotely located node (.atmf).
Node ID A unique identifier assigned to a Node on an AMF network.
Node Depth The number of nodes in path from this node to level of the AMF root node. It can be
thought of as the vertical depth of the AMF network from a particular node to the
zero level of the AMF root node.
Domain State The state of Node in a Domain in AMF network as Controller/Backup.
Recovery State The AMF node recovery status. Indicates whether a node recovery is in progress on
this device - Auto, Manual, or None.
Management VLAN The VLAN created for traffic between Nodes of different domain (up/down links).
• VLAN ID - In this example VLAN 4092 is configured as the Management VLAN.
• Management Subnet - Network prefix for the subnet.
• Management IP Address - The IP address allocated for this traffic.
• Management Mask - The subnet mask used to create a subnet for this traffic
(255.255.128.0).
Domain VLAN The VLAN assigned for traffic between Nodes of same domain (crosslink).
• VLAN ID - In this example VLAN 4091 is configured as the domain VLAN.
• Domain Subnet. The subnet address used for this traffic.
• Domain IP Address. The IP address allocated for this traffic.
• Domain Mask. The subnet mask used to create a subnet for this traffic
(255.255.128.0).
Device Type The Product Series name.
ATMF Master Whether the node is an AMF master node for its area (‘Y‘ if it is and ‘N’ if it is not).
SC The device configuration, one of C - Chassis (SBx8100 Series), S - Stackable (VCS) or N
- Standalone.
Parent The node to which the current node has an active uplink.
Node Depth The number of nodes in the path from this node to the master node.
Table 4: Parameter definitions from the show atmf tech command (cont.)
Parameter Definition
