Switch(config-if)# dot1x critical vlan 20
Switch(config-if)# end
Configuring 802.1x Authentication with WoL
Beginning in privileged EXEC mode, follow these steps to enable 802.1x authentication with WoL. This
procedure is optional.
SUMMARY STEPS
1.
configure terminal
2.
interface interface-id
3.
authentication control-direction {both | in}
4.
end
5.
show authentication sessions interface interface-id
6.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Specifies the port to be configured, and enter interface
configuration mode.
interface interface-id
Example:
Switch(config)# interface gigabitethernet2/0/3
Step 2
Enables 802.1x authentication with WoL on the port, and use
these keywords to configure the port as bidirectional or
unidirectional.
authentication control-direction {both | in}
Example:
Switch(config-if)# authentication
Step 3
• both—Sets the port as bidirectional. The port cannot
receive packets from or send packets to the host. By
default, the port is bidirectional.
control-direction both
• in—Sets the port as unidirectional. The port can send
packets to the host but cannot receive packets from the
host.
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
1387
How to Configure 802.1x Port-Based Authentication

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
