DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode. Enter your password if prompted.enable
Step 1
Example:
Switch> enable
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Removes any existing SPAN configuration for the session.
no monitor session {session_number | all |
local | remote}
Step 3
•
For session_number, the range is 1 to 66.
Example:
Switch(config)# no monitor session 1
• all—Removes all SPAN sessions.
• local—Removes all local sessions.
• remote—Removes all remote SPAN sessions.
Specifies the RSPAN session and the source port (monitored port).
monitor session session_number source
{interface interface-id | vlan vlan-id} [, | -]
[both | rx | tx]
Step 4
•
For session_number, the range is 1 to 66.
Example:
Switch(config)# monitor session 1
•
Enter a source port or source VLAN for the RSPAN session:
◦
For interface-id, specifies the source port to monitor. Valid
interfaces include physical interfaces and port-channel logical
source interface gigabitethernet1/0/1
tx
interfaces (port-channel port-channel-number). Valid
port-channel numbers are 1 to 48.
◦
For vlan-id, specifies the source VLAN to monitor. The range
is 1 to 4094 (excluding the RSPAN VLAN).
A single session can include multiple sources (ports or VLANs),
defined in a series of commands, but you cannot combine
source ports and source VLANs in one session.
• (Optional) [, | -]—Specifies a series or range of interfaces. Enter a
space before and after the comma; enter a space before and after the
hyphen.
• (Optional) both | rx | tx—Specifies the direction of traffic to monitor.
If you do not specify a traffic direction, the source interface sends
both sent and received traffic.
◦ both—Monitors both received and sent traffic.
◦ rx—Monitors received traffic.
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
493
How to Configure SPAN and RSPAN
