PurposeCommand or Action
Creates a flow exporter and enters flow exporter
configuration mode.
flow exporter name
Example:
Switch(config)# flow exporter ExportTest
Step 2
(Optional) Describes this flow record as a maximum
63-character string.
description string
Example:
Switch(config-flow-exporter)# description
Step 3
ExportV9
Sets the IPv4 destination address or hostname for this
exporter.
destination {ipv4-address} [ vrf vrf-name]
Example:
Switch(config-flow-exporter)# destination
Step 4
192.0.2.1 (IPv4 destination)
(Optional) Specifies the differentiated services codepoint
value. The range is from 0 to 63. The default is 0.
dscp value
Example:
Switch(config-flow-exporter)# dscp 0
Step 5
(Optional) Specifies the interface to use to reach the
NetFlow collector at the configured destination. The
following interfaces can be configured as source:
source { source type }
Example:
Switch(config-flow-exporter)# source
Step 6
gigabitEthernet1/0/1
(Optional) Specifies the UDP port to use to reach the
NetFlow collector. The range is from 1 to 65536
transport udp number
Example:
Switch(config-flow-exporter)# transport udp
Step 7
200
(Optional) Configures the time-to-live (TTL) value for
datagrams sent by the exporter. The range is from 1 to 255
seconds. The default is 255.
ttl seconds
Example:
Switch(config-flow-exporter)# ttl 210
Step 8
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
524
How to Configure NetFlow Lite

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
