PurposeCommand or Action
Example:
Switch> enable
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Adds a static address to the MAC address table.
mac address-table static mac-addr vlan
vlan-id interface interface-id
Step 3
•
mac-addr—Specifies the destination MAC unicast address to add
to the address table. Packets with this destination address received
in the specified VLAN are forwarded to the specified interface.
Example:
Switch(config)# mac address-table
•
vlan-id—Specifies the VLAN for which the packet with the
specified MAC address is received. Valid VLAN IDs are 1 to 4094.
static c2f3.220a.12f4 vlan 4 interface
gigabitethernet 1/0/1
•
interface-id—Specifies the interface to which the received packet
is forwarded. Valid interfaces include physical ports or port
channels. For static multicast addresses, you can enter multiple
interface IDs. For static unicast addresses, you can enter only one
interface at a time, but you can enter the command multiple times
with the same MAC address and VLAN ID.
Returns to privileged EXEC mode. Alternatively, you can also press
Ctrl-Z to exit global configuration mode.
end
Example:
Switch(config)# end
Step 4
Verifies your entries.show running-config
Example:
Switch# show running-config
Step 5
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config
Step 6
startup-config
Configuring Unicast MAC Address Filtering
Follow these steps to configure the Switch to drop a source or destination unicast static address:
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
1551
How to Administer the Switch

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
