PurposeCommand or Action
30
Returns to global configuration mode.end
Example:
Switch(config-if)# end
Step 13
Repeat Steps 9 through 13 on the other configured trunk
interface on Switch A, and set the spanning-tree path
cost to 30 for VLANs 8, 9, and 10.
Step 14
Returns to privileged EXEC mode.exit
Example:
Switch(config)# exit
Step 15
Verifies your entries. In the display, verify that the path
costs are set correctly for both trunk interfaces.
show running-config
Example:
Switch# show running-config
Step 16
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config startup-config
Step 17
Related Topics
Network Load Sharing Using STP Path Cost, on page 2132
Configuration Examples for VLAN Trunking
Example: Configuring a Trunk Port
The following example shows how to configure a port as an IEEE 802.1Q trunk. The example assumes that
the neighbor interface is configured to support IEEE 802.1Q trunking.
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# interface gigabitethernet1/0/2
Switch(config-if)# switchport mode dynamic desirable
Switch(config-if)# end
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
2148
Configuration Examples for VLAN Trunking

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
