ID Test Name Attributes day hh:mm:ss.ms shold
==== ================================== ============ =============== =====
1) TestPortAsicStackPortLoopback ---> B*N****I** not configured n/a
2) TestPortAsicLoopback ------------> B*D*X**IR* not configured n/a
3) TestPortAsicCam -----------------> B*D*X**IR* not configured n/a
4) TestPortAsicRingLoopback --------> B*D*X**IR* not configured n/a
5) TestMicRingLoopback -------------> B*D*X**IR* not configured n/a
6) TestPortAsicMem -----------------> B*D*X**IR* not configured n/a
This example shows how to display the online diagnostic results for a switch:
Switch# show diagnostic result
Switch 1: SerialNo :
Overall diagnostic result: PASS
Test results: (. = Pass, F = Fail, U = Untested)
1) TestPortAsicStackPortLoopback ---> .
2) TestPortAsicLoopback ------------> .
3) TestPortAsicCam -----------------> .
4) TestPortAsicRingLoopback --------> .
5) TestMicRingLoopback -------------> .
6) TestPortAsicMem -----------------> .
This example shows how to display the online diagnostic test status:
Switch# show diagnostic status
<BU> - Bootup Diagnostics, <HM> - Health Monitoring Diagnostics,
<OD> - OnDemand Diagnostics, <SCH> - Scheduled Diagnostics
====== ================================= =============================== ======
Card Description Current Running Test Run by
------ --------------------------------- --------------------- ------
1 N/A N/A
2 TestPortAsicStackPortLoopback <OD>
TestPortAsicLoopback <OD>
TestPortAsicCam <OD>
TestPortAsicRingLoopback <OD>
TestMicRingLoopback <OD>
TestPortAsicMem <OD>
3 N/A N/A
4 N/A N/A
====== ================================= =============================== ======
Switch#
This example shows how to display the online diagnostic test schedule for a switch:
Switch# show diagnostic schedule switch 1
Current Time = 14:39:49 PST Tue May 5 2013
Diagnostic for Switch 1:
Schedule #1:
To be run daily 12:00
Test ID(s) to be executed: 1.
Additional References for Online Diagnostics
Related Documents
Document TitleRelated Topic
Catalyst 2960-X Switch System
Management Command Reference
Online diagnostics commands
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
1622
Additional References for Online Diagnostics

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
