PurposeCommand or Action
extended maclist1
Specifies the type of traffic to permit or deny if the conditions are matched,
entering the command as many times as necessary.
{permit | deny} {host src-MAC-addr mask
| any | host dst-MAC-addr | dst-MAC-addr
mask} [type mask]
Step 3
•
For src-MAC-addr, enter the MAC address of the host from which
the packet is being sent. You specify this by using the hexadecimal
Example:
Switch(config-ext-mac1) # permit
format (H.H.H), by using the any keyword as an abbreviation for
source 0.0.0, source-wildcard ffff.ffff.ffff, or by using the host
keyword for source 0.0.0.
0001.0000.0001
0.0.0 0002.0000.0001 0.0.0
Switch(config-ext-mac1) # permit
•
For mask, enter the wildcard bits by placing ones in the bit positions
that you want to ignore.
0001.0000.0002
0.0.0 0002.0000.0002 0.0.0 xns-idp
•
For dst-MAC-addr, enter the MAC address of the host to which the
packet is being sent. You specify this by using the hexadecimal format
(H.H.H), by using the any keyword as an abbreviation for source
0.0.0, source-wildcard ffff.ffff.ffff, or by using the host keyword for
source 0.0.0.
•
(Optional) For type mask, specify the Ethertype number of a packet
with Ethernet II or SNAP encapsulation to identify the protocol of the
packet. For type, the range is from 0 to 65535, typically specified in
hexadecimal. For mask, enter the don’t care bits applied to the
Ethertype before testing for a match.
When creating an access list, remember that, by default, the end of the access
list contains an implicit deny statement for everything if it did not find a
match before reaching the end.
Returns to privileged EXEC mode.end
Example:
Switch(config-ext-mac1)# end
Step 4
Verifies your entries.
show access-lists [access-list-number |
access-list-name]
Step 5
Example:
Switch# show access-lists
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy-running-config
Step 6
startup-config
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
591
How to Configure QoS

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
