DescriptionCommand
Displays LACP information such as traffic
information, the internal LACP configuration, and
neighbor information.
show lacp [ channel-group-number ] { counters |
internal | neighbor | sys-id}
Verifies your configuration entries.show running-config
Displays the load balance or frame distribution
scheme among ports in the port channel.
show etherchannel load-balance
Related Topics
Configuring the PAgP Learn Method and Priority , on page 348
PAgP Learn Method and Priority, on page 330
Configuring the LACP System Priority , on page 350
Configuring the LACP Port Priority , on page 351
Configuration Examples for Configuring EtherChannels
Configuring Layer 2 EtherChannels: Examples
This example shows how to configure an EtherChannel on a single switch in the stack. It assigns two ports
as static-access ports in VLAN 10 to channel 5 with the PAgP mode desirable:
Switch# configure terminal
Switch(config)# interface range gigabitethernet2/0/1 -2
Switch(config-if-range)# switchport mode access
Switch(config-if-range)# switchport access vlan 10
Switch(config-if-range)# channel-group 5 mode desirable non-silent
Switch(config-if-range)# end
This example shows how to configure an EtherChannel on a single switch in the stack. It assigns two ports
as static-access ports in VLAN 10 to channel 5 with the LACP mode active:
Switch# configure terminal
Switch(config)# interface range gigabitethernet2/0/1 -2
Switch(config-if-range)# switchport mode access
Switch(config-if-range)# switchport access vlan 10
Switch(config-if-range)# channel-group 5 mode active
Switch(config-if-range)# end
This example shows how to configure a cross-stack EtherChannel. It uses LACP passive mode and assigns
two ports on stack member 1 and one port on stack member 2 as static-access ports in VLAN 10 to channel
5:
Switch# configure terminal
Switch(config)# interface range gigabitethernet2/0/4 -5
Switch(config-if-range)# switchport mode access
Switch(config-if-range)# switchport access vlan 10
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
359
Configuration Examples for Configuring EtherChannels

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
