Cisco Catalyst 2960 Series User Manual

Enhanced Automatically Generated Command
{Video|Trust|Classify}
Automatically Generated
Command {voip}
Description
The switch
automatically
configures the egress
queue buffer sizes. It
configures the
bandwidth and the SRR
mode (shaped or
shared) on the egress
queues mapped to the
port.
Switch(config)# mls qos queue-set
output 1 threshold 2 100 100 50 200
Switch(config)# mls qos queue-set
output 1 threshold 2 125 125 100 400
Switch(config)# mls qos queue-set
output 1 threshold 3 100 100 100 400
Switch(config)# mls qos queue-set
output 1 threshold 4 60 150 50 200
Switch(config)# mls qos queue-set
output 1 buffers 15 25 40 20
Switch(config)# mls qos
queue-set
output 1 threshold 1 138 138
92 138
Switch(config)# mls qos
queue-set
output 1 threshold 2 138 138
92 400
Switch(config)# mls qos
queue-set
output 1 threshold 3 36 77
100 318
Switch(config)# mls qos
queue-set
output 1 threshold 4 20 50 67
400
Switch(config)# mls qos
queue-set
output 2 threshold 1 149 149
100 149
Switch(config)# mls qos
queue-set
output 2 threshold 2 118 118
100 235
Switch(config)# mls qos
queue-set
output 2 threshold 3 41 68
100 272
Switch(config)# mls qos
queue-set
output 2 threshold 4 42 72
100 242
Switch(config)# mls qos
queue-set
output 1 buffers 10 10 26 54
Switch(config)# mls qos
queue-set
output 2 buffers 16 6 17 61
Switch(config-if)#
priority-queue
out
Switch(config-if)# srr-queue
bandwidth share 10 10 60 20
Examples: Auto-QoS Generated Configuration for VoIP Devices
The following table describes the automatically generated commands for auto-QoS for VoIP devices by the
switch.
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
658
Configuration Examples for Auto-Qos
