Page #542 background imageLoading...
Page #542 background image
DescriptionNotification Type Keyword
Generates a trap for Hot Standby Router Protocol (HSRP) changes.hsrp
Generates a trap for IP multicast routing changes.ipmulticast
Generates a trap for MAC address notifications.mac-notification
Generates a trap for Multicast Source Discovery Protocol (MSDP)
changes.
msdp
Generates a trap for Open Shortest Path First (OSPF) changes. You
can enable any or all of these traps: Cisco specific, errors, link-state
advertisement, rate limit, retransmit, and state changes.
ospf
Generates a trap for Protocol-Independent Multicast (PIM) changes.
You can enable any or all of these traps: invalid PIM messages,
neighbor changes, and rendezvous point (RP)-mapping changes.
pim
Generates SNMP port security traps. You can also set a maximum
trap rate per second. The range is from 0 to 1000; the default is 0,
which means that there is no rate limit.
When you configure a trap by using the notification type
port-security, configure the port security trap first, and
then configure the port security trap rate:
Note
1
snmp-server enable traps port-security
2
snmp-server enable traps port-security trap-rate rate
port-security
Generates a trap for the SNMP Response Time Reporter (RTR).rtr
Generates a trap for SNMP-type notifications for authentication,
cold start, warm start, link up or link down.
snmp
Generates a trap for SNMP storm-control. You can also set a
maximum trap rate per minute. The range is from 0 to 1000; the
default is 0 (no limit is imposed; a trap is sent at every occurrence).
storm-control
Generates SNMP STP Extended MIB traps.stpx
Generates SNMP syslog traps.syslog
Generates a trap for TCP connections. This trap is enabled by default.tty
Generates a trap for SNMP VLAN membership changes.vlan-membership
Generates SNMP VLAN created traps.vlancreate
Generates SNMP VLAN deleted traps.vlandelete
Generates a trap for VLAN Trunking Protocol (VTP) changes.vtp
Follow these steps to configure the switch to send traps or informs to a host.
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
460
How to Configure SNMP
