DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode. Enter your password if prompted.enable
Example:
Switch> enable
Step 1
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Defines an extended MAC access list using a name.
mac access-list extended name
Example:
Switch(config)# mac access-list extended mac1
Step 3
In extended MAC access-list configuration mode, specifies to
permit or deny any source MAC address, a source MAC address
{deny | permit} {any | host source MAC address |
source MAC address mask} {any | host destination
Step 4
with a mask, or a specific host source MAC address and any
MAC address | destination MAC address mask} [type
destination MAC address, destination MAC address with a mask,
or a specific destination MAC address.
mask | lsap lsap mask | aarp | amber | dec-spanning
| decnet-iv | diagnostic | dsm | etype-6000 |
etype-8042 | lat | lavc-sca | mop-console |
(Optional) You can also enter these options:
mop-dump | msdos | mumps | netbios | vines-echo
| vines-ip | xns-idp | 0-65535] [cos cos]
• type mask—An arbitrary EtherType number of a packet with
Ethernet II or SNAP encapsulation in decimal, hexadecimal,
Example:
Switch(config-ext-macl)# deny any any
or octal with optional mask of don’t care bits applied to the
EtherType before testing for a match.
• lsap lsap mask—An LSAP number of a packet with
IEEE 802.2 encapsulation in decimal, hexadecimal, or octal
with optional mask of don’t care bits.
decnet-iv
or
Switch(config-ext-macl)# permit any any
•
aarp | amber | dec-spanning | decnet-iv | diagnostic | dsm
| etype-6000 | etype-8042 | lat | lavc-sca | mop-console |
mop-dump | msdos | mumps | netbios | vines-echo | vines-ip
| xns-idp—A non-IP protocol.
• cos cos—An IEEE 802.1Q cost of service number from 0 to
7 used to set priority.
Returns to privileged EXEC mode.end
Example:
Switch(config-ext-macl)# end
Step 5
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
1249
How to Configure VLAN Access Control Lists

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
