Page #1541 background imageLoading...
Page #1541 background image
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Configures an interface and enters interface
configuration mode.
interface type number
Example:
Switch(config)# interface gigabitethernet 1/0/1
Step 3
Configures a source template for the interface.source template {AI_CLOSED_MODE |
AI_LOW_IMPACT_MODE | AI_MONITOR_MODE |
template-name} [merge]
Step 4
Example:
Switch(config-if)# source template AI_CLOSED_MODE
(Optional) Configures a source template for the
interface and merges this template with the previously
configured template
source template {AI_CLOSED_MODE |
AI_LOW_IMPACT_MODE | AI_MONITOR_MODE |
template-name} [merge]
Example:
Switch(config-if)# source template AI_MONITOR_MODE
merge
Step 5
When you configure two templates, if you do not
configure the merge keyword, the last configured
template is used.
Sets the VLAN when the interface is in access mode.
switchport access vlan vlan-id
Example:
Switch(config-if)# switchport access vlan 100
Step 6
Configures a voice VLAN on a multiple VLAN access
port.
switchport voice vlan vlan-id
Example:
Switch(config-if)# switchport voice vlan 101
Step 7
Repeat Steps 4, 6, and 7 on all interfaces that must have the
Auto Identity feature configured.
Step 8
Exits interface configuration mode and returns to
privileged EXEC mode.
end
Example:
Switch(config-if)# end
Step 9
Configuration Examples for Auto Identity
Example: Configuring Auto Identity Globally
Switch> enable
Switch# configure terminal
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
1459
Auto Identity
