Cisco Catalyst 2960 Series User Manual

Related Topics
Flexible Authentication Ordering, on page 1347
Configuring Open1x
Beginning in privileged EXEC mode, follow these steps to enable manual control of the port authorization
state:
SUMMARY STEPS
1.
configure terminal
2.
interface interface-id
3.
switchport mode access
4.
authentication control-direction {both | in}
5.
authentication fallback name
6.
authentication host-mode [multi-auth | multi-domain | multi-host | single-host]
7.
authentication open
8.
authentication order [ dot1x | mab ] | {webauth}
9.
authentication periodic
10.
authentication port-control {auto | force-authorized | force-un authorized}
11.
end
DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Specifies the port to be configured, and enter interface
configuration mode.
interface interface-id
Example:
Switch(config)# interface gigabitethernet 1/0/1
Step 2
Sets the port to access mode only if you configured
the RADIUS server.
switchport mode access
Example:
Switch(config-if)# switchport mode access
Step 3
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
1407
How to Configure 802.1x Port-Based Authentication

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
