Table 79: Generated Auto-QoS Configuration for VoIP Devices
Automatically Generated Command (VoIP)Description
Switch(config)# mls qos
Switch(config)# mls qos map cos-dscp 0 8 16 26 32
46 48 56
The switch automatically
enables standard QoS and
configures the CoS-to-DSCP
map (maps CoS values in
incoming packets to a DSCP
value).
Switch(config)# no mls qos srr-queue output cos-map
Switch(config)# mls qos srr-queue output cos-map queue 1
threshold 3 5
Switch(config)# mls qos srr-queue output cos-map queue 2
threshold 3 3 6 7
Switch(config)# mls qos srr-queue output cos-map queue 3
threshold 3 2 4
Switch(config)# mls qos srr-queue output cos-map queue 4
threshold 2 1
Switch(config)# mls qos srr-queue output cos-map queue 4
threshold 3 0
The switch automatically maps
CoS values to an egress queue
and to a threshold ID.
Switch(config)# no mls qos srr-queue output dscp-map
Switch(config)# mls qos srr-queue output dscp-map queue 1
threshold 3 40 41 42 43 44 45 46 47
Switch(config)# mls qos srr-queue output dscp-map queue 2
threshold 3 24 25 26 27 28 29 30 31
Switch(config)# mls qos srr-queue output dscp-map queue 2
threshold 3 48 49 50 51 52 53 54 55
Switch(config)# mls qos srr-queue output dscp-map queue 2
threshold 3 56 57 58 59 60 61 62 63
Switch(config)# mls qos srr-queue output dscp-map queue 3
threshold 3 16 17 18 19 20 21 22 23
Switch(config)# mls qos srr-queue output dscp-map queue 3
threshold 3 32 33 34 35 36 37 38 39
Switch(config)# mls qos srr-queue output dscp-map queue 4
threshold 1 8
Switch(config)# mls qos srr-queue output dscp-map queue 4
threshold 2 9 10 11 12 13 14 15
Switch(config)# mls qos srr-queue output dscp-map queue 4
threshold 3 0 1 2 3 4 5 6 7
The switch automatically maps
DSCP values to an egress
queue and to a threshold ID.
The switch automatically
configures the egress queue
buffer sizes. It configures the
bandwidth and the SRR mode
(shaped or shared) on the
egress queues mapped to the
port.
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
659
Configuration Examples for Auto-Qos

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
