Cisco Catalyst 2960 Series User Manual

SUMMARY STEPS
1.
enable
2.
configure terminal
3.
event manager applet applet-name
4.
action label foreach [string-iterator] [string-input] [string-delimiter]
5.
Specify any action command
6.
action label end
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Device> enable
•
Enter your password if prompted.
Enters global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Registers the applet with the Embedded Event Manager (EEM)
and enters applet configuration mode.
event manager applet applet-name
Example:
Device(config)# event manager applet iteration
Step 3
Iterates over an input string using the delimter as a tokenizing
pattern.
action label foreach [string-iterator] [string-input]
[string-delimiter]
Step 4
Example:
Device(config-applet)# action 2.0 foreach
iterator "red blue green orange"
•
In this example, the iteration is run through the elements
of the input string - red, blue, green and orange.
Performs the action as indicated by the action command.Specify any action command
Step 5
Example:
Device(config-applet)# action 3.0 puts
"Iterator is $iterator"
•
In this example, the following message is displayed on
the screen:
Iterator is red
Iterator is blue
Iterator is green
Iterator is orange
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
1737
How to Write EEM Policies Using the Cisco IOS CLI

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
