Table 78: Generated Auto-QoS Configuration
Enhanced Automatically Generated Command
{Video|Trust|Classify}
Automatically Generated
Command {voip}
Description
Switch(config)# mls qos
Switch(config)# mls qos map cos-dscp
0 8 16 24 32 46 48 56
Switch(config)# mls qos
Switch(config)# mls qos map
cos-dscp
0 8 16 26 32 46 48 56
The switch
automatically enables
standard QoS and
configures the
CoS-to-DSCP map
(maps CoS values in
incoming packets to a
DSCP value).
Switch(config)# no mls qos srr-queue
output cos-map
Switch(config)# mls qos srr-queue
output cos-map queue 1 threshold 3 4 5
Switch(config)# mls qos srr-queue
output cos-map queue 2 threshold 3 6 7
Switch(config)# mls qos srr-queue
output cos-map queue 2 threshold 1 2
Switch(config)# mls qos srr-queue
output cos-map queue 2 threshold 2 3
Switch(config)# mls qos srr-queue
output cos-map queue 3 threshold 3 0
Switch(config)# mls qos srr-queue
output cos-map queue 4 threshold 3 1
Switch(config)# no mls qos
srr-queue
output cos-map
Switch(config)# mls qos
srr-queue
output cos-map queue 1
threshold 3 5
Switch(config)# mls qos
srr-queue
output cos-map queue 2
threshold 3 3
6 7
Switch(config)# mls qos
srr-queue
output cos-map queue 3
threshold 3 2
4
Switch(config)# mls qos
srr-queue
output cos-map queue 4
threshold 2 1
Switch(config)# mls qos
srr-queue
output cos-map queue 4
threshold 3 0
The switch
automatically maps
CoS values to an egress
queue and to a
threshold ID.
The switch
automatically maps
DSCP values to an
egress queue and to a
threshold ID.
Consolidated Platform Configuration Guide, Cisco IOS Release 15.2(4)E (Catalyst 2960-X Switches)
656
Configuration Examples for Auto-Qos

Cisco Catalyst 2960 Series Specifications

General

Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
RAM	128 MB
Flash Memory	32 MB
MAC Address Table Size	8000
Operating Temperature	0°C to 45°C (32 to 113°F)
Ports	24 or 48 x 10/100/1000
