C613-50100-01 REV C Command Reference for x930 Series 1863
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
IPV4 HARDWARE ACCESS CONTROL LIST (ACL) COMMANDS
ACCESS
-LIST (HARDWARE IP NUMBERED)
<source> The source address of the packets. You can specify a single host,
a subnet, or all sources. The following are the valid formats for
specifying the source:
any Matches any source IP address.
host<ip-addr> Matches a single source host with the IP
address given by <ip-addr> in dotted
decimal notation.
<ip-addr>/
<prefix>
An IPv4 address, followed by a forward
slash, then the prefix length. This
matches any source IP address within the
specified subnet.
<ip-addr>
<reverse-mask>
Alternatively, you can enter a reverse
mask in dotted decimal format. For
example, entering 192.168.1.1
0.0.0.255 is the same as entering
192.168.1.1/24.
<destination> The destination address of the packets. You can specify a single
host, a subnet, or all destinations. The following are the valid
formats for specifying the destination:
any Matches any destination IP address.
host <ip-addr> Matches a single destination host with
the IP address given by <ip-addr> in
dotted decimal notation.
<ip-addr>/
<prefix>
An IPv4 address, followed by a forward
slash, then the prefix length. This
matches any destination IP address
within the specified subnet.
<ip-addr>
<reverse-mask>
Alternatively, you can enter a reverse
mask in dotted decimal format. For
example, entering 192.168.1.1
0.0.0.255 is the same as entering
192.168.1.1/24.
icmp-type Matches only a specified type of ICMP messages. This is valid
only when the filtering is set to match ICMP packets.
Table 38: Parameters in the access-list (hardware IP numbered) command -
ip|icmp (cont.)
Parameter Description
