C613-50100-01 REV C Command Reference for x930 Series 324
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
PLUGGABLES AND CABLING COMMANDS
SHOW
SYSTEM PLUGGABLE DIAGNOSTICS
Output Figure 8-7: Example output from the show system pluggable diagnostics
command on a device
Output Figure 8-8: Example output from the show system pluggable diagnostics
command for a switch with a QSFP+ DAC in port 1.1.1 and a QSFP+
awplus#show system pluggable diagnostics
System Pluggable Information Diagnostics
Port1.0.25 Status Alarms Warnings
Reading Alarm Max Min Warning Max Min
Temp: (Degrees C) 29.387 - 100.00 -40.00 - 85.000 -10.00
Vcc: (Volts) 3.339 - 3.465 3.135 - 3.400 3.200
Tx Bias: (mA) 10.192 - 37.020 3.260 - 34.520 5.760
Tx Power: (mW) 17.872 - 35.643 8.953 - 28.313 11.271
Rx Power: (mW) 0.006 Low 15.849 0.025 Low 12.589 0.040
Rx LOS: Rx Down
Port1.0.26 Status Alarms Warnings
Reading Alarm Max Min Warning Max Min
Temp: (Degrees C) 29.387 - 100.00 -40.00 - 85.000 -10.00
Vcc: (Volts) 3.378 - 3.630 2.970 - 3.465 3.135
Tx Bias: (mA) 2.802 - 6.000 1.000 - 5.000 1.000
Tx Power: (mW) 2.900 - 11.000 0.600 - 10.000 0.850
Rx Power: (mW) 1.739 - 18.000 0.000 - 10.000 0.200
Rx LOS: Rx Up
