C613-50100-01 REV C Command Reference for x930 Series 686
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
POWER OVER ETHERNET COMMANDS
SHOW
POWER-INLINE INTERFACE DETAIL
Table 4: Parameters in show power-inline interface detail command output
Parameter Description
Interface The PoE port(s) in the format portx.y.z, where x is the device
number, y is the module number within the device, and z is the
PoE port number within the module.
Powered
device type:
The name of the PD, if connected and if power is being supplied
to the PD from the PSE, configured with the power-inline
description command. n/a displays if a description has not been
configured for the PD.
PoE admin The administrative state of PoE on a PoE capable port, either
Enabled or Disabled as configured from the power-inline enable
command or the no power-inline enable command
respectively.
Priority The PoE priority of a port, which is either Low, or High, or
Critical, as configured by the power-inline priority command.
Detection
status:
The current PSE PoE port state when this command was issued:
• Powered displays when there is a PD connected and power is
being supplied from the PSE.
• Denied displays when supplying power would make the PSE
go over the power budget.
• Disabled displays when the PoE port is administratively
disabled.
• Off displays when PoE has been disabled for the port.
• Fault displays when a PSE goes over its power allocation.
Current power
consumption:
The power consumption for the PoE port when this command
was entered. Note that the power consumption may have
changed since the command was entered and the power is
displayed.
Powered
device class:
The class of the connected PD if connected, and if power is being
supplied to the PD from the PSE.
See the PoE Feature Overview and Configuration Guide for
further information about power classes.
Power
allocated:
The power in milliwatts (mW) allocated for the PoE port.
Additionally, note the following as displayed per PoE port:
• [U] if the power limit for a port was user configured (with the
power-inline max command).
• [L] if the power limit for a port was supplied by LLDP.
• [C] if the power limit for a port was supplied by the PD class.
