Chapter 4: C4 CMTS General Installation Requirements
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 102
CAUTION: Fan filters cannot be cleaned and re-used.
Figure 6: Internal Air Flow (side view)
CAUTION: Care should be taken when dressing RF cables such that they do not obstruct the grillwork at the top rear of the
chassis. This grill is the primary heat vent for the chassis. Blocking it can cause overheating and card failure. Allow sufficient
clearance for airflow around the chassis.
Rack Mounting the C4 CMTS
The following steps outline how to rack mount the C4 CMTS.
