Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure cable load-interval

Purpose

Configures the interval for utilization calculations.

Default Access Level

Command Syntax

configure cable load-interval <300-86400>

configure cable load-interval no

Supplemental

Information

Note: Changes to the cable load-interval are not immediate and will take effect after the current interval has expired.

WARNING: On large systems, setting this value to low will drain CPU resources. The minimum recommended value is 300 seconds.

To disable the interval used for utilization calculations, use the no option

Parameters

<300-86400>

The interval in seconds to collect/compute utilization data.

Related Commands

show cable load-balance (page 2659)
