Arris C4C User Manual

Chapter 46: Command Line Descriptions
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 2166
configure l2vpn forwarding
Purpose
Controls the L2VPN forwarding state on a global, instance, L2VPN ID, or CM basis.
Default Access Level
15
Command Syntax
configure l2vpn forwarding [l2vpnid <id>] [instance <outer-vlanid> |<inner-vlanid>] [cm-mac <mac_id>]
{enable|disable}
Supplemental
Information
N/A
Parameters
[l2vpnid<id>]
Externally configured string that identifies a specific L2VPN
instance<outer-
vlanid> |
The VLAN identifier used for single or dual Q-tags. Range is 2 - 4094.
<inner-vlanid>
Optional smaller VLAN identifier used with dual Q-tags. Range is 1 - 4095.
cm-mac <mac_id>
CM MAC ID of the L2VPN registered cable modem
{enable | disable}
Enable or disable the global L2VPN forwarding state
