Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure aging

Purpose

Configures the aging intervals for the ARP cache.

Default Access Level

Command Syntax

configure aging [idle-mac <seconds>] [stale-mac <seconds>]

configure aging [idle-mac <seconds>] [stale-mac <seconds>] no

Supplemental

Information

To reset to the default, use the no option.

Parameters

[idle-mac

<seconds>]

The idle MAC aging time in seconds. Valid range is 10-1000000 seconds. Default idle-mac = 1800 seconds

[stale-mac

<seconds>]

The length of time (in seconds) that inactive MAC addresses are maintained in the C4 CMTS’s internal database. Valid range is 11-

1000000 seconds. Default stale-mac = 604800 seconds.
