An output similar to the following example would result:
MAC US DS Method
----- ---------- -------- -----------
1 3/0/0 12/0/0 Provisioned
1 3/0/0 12/0/1 Provisioned
1 3/0/0 12/0/2 Provisioned
1 3/0/0 12/0/3 Provisioned
1 3/0/1 12/0/0 Provisioned
1 3/0/1 12/0/1 Provisioned
1 3/0/1 12/0/2 Provisioned
1 3/0/1 12/0/3 Provisioned
1 3/0/2 12/0/0 Provisioned
1 3/0/2 12/0/1 Provisioned
•
•
•
8 3/7/11 12/7/8 Provisioned
8 3/7/11 12/7/9 Provisioned
8 3/7/11 12/7/10 Provisioned
8 3/7/11 12/7/11 Provisioned
8 3/7/11 12/7/12 Provisioned
8 3/7/11 12/7/13 Provisioned
8 3/7/11 12/7/14 Provisioned
8 3/7/11 12/7/15 Provisioned
Note: The output provided for command execution on slot 3 would be the same.
Cable Plant Topology and Fiber Nodes
The C4/c CMTS is responsible for assigning an upstream Transmit Channel Configuration (TCC) and a downstream Receive
Channel Configuration (RCC) to each cable modem that is capable of supporting them. DOCSIS 3.0 provides for the flexible
assignment of multiple upstream or downstream channels to carry a single packet flow.
As a result, the C4/c CMTS is required to provide enhanced tracking of the cable plant topology than was previously
necessary for earlier DOCSIS phases. Specifically, the C4/c CMTS must be aware of which upstream and downstream
channels reach each cable modem.
The following steps are necessary to achieve this tracking functionality:
Provisioning of fiber nodes in the cable plant
To Next Page
