Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure logging snmp

Purpose

Causes all trappable notifications with specified priority level to be sent to an SNMP manager (if configured) as an SNMP trap.

Default Access Level

Command Syntax

configure logging snmp <level>

configure logging snmp <level> no

Supplemental

Information

By default, the C4 CMTS generates SNMP traps for any event with a priority level of critical (3), error (4), warning (5), or notice (6).

To turn off all SNMP logging for all logging levels, use the no option.

Parameters

<level>

Values of priority level are:

1 = emergency 5 = warning

2 = alert 6 = notice

3 = critical 7 = informational

4 = error 8 = debug
