Chapter 5: C4c CMTS Installation Requirements

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

Chassis — Rear View

Physical Interface Cards (PICs)

Smaller modules, called Physical Interface Cards, or PICs, are inserted in each slot from the rear of the chassis. The PICs

provide physical connectors for terminating cables from the subscriber network and enable the CAMs to be replaced

without having to remove cables.

The figure below shows an example of a rear view of a chassis configured with 12U and 16D CAMs to show their

connectors.

 Slots 10-15 are equipped with CAM PICs

 Slot 19 is equipped with an SCM PIC

 There is no rear slot 17 and the RCM has no PIC.

Figure 28: C4c CMTS Chassis (rear view)
