Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show running-config interface cable-upstream

Purpose

The show running-config interface command shows the parameters for the specified upstream cable interface.

Default Access Level

Command Syntax

show running-config interface cable-upstream <slot/port> [verbose] [linenum] [full]

Supplemental

Information

N/A

Parameters

The upstream slot/port.

[verbose]

Displays the output with ‘configure’ on each line.

[linenum]

Enumerates each line with its line number in the output.

[full]

Displays all configuration values, including default values.
