Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure shelfname

Purpose

Configures the shelf name or name of the chassis.

Default Access Level

Command Syntax

configure shelfname <shelf name>

Supplemental

Information

N/A

Parameters

Use this command if you want to define a name for the CMTS.
