Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure arp state not-present global-max-rate

Purpose

Sets the maximum number of ICMP unreachables per second transmitted for all NotPresent IPs.

Default Access Level

Command Syntax

configure arp state not-present global-max-rate <0-65535>

configure arp state not-present global-max-rate [<0-65535>] no

Supplemental

Information

To reset the number of ICMP unreachables per second to the default value, use the no option.

Parameters

<0-65535>

Rate in packets/second for ICMPs.

Related Commands

configure arp state not-present max-number (page 1232)

configure arp state not-present rate-limit (page 1235)
