Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure ipv6 nd state not-present rate-limit

Purpose

Configures the Neighbor Discovery state not-present limits.

Default Access

Level

Command Syntax

configure ipv6 nd state not-present rate-limit <100-86400000>

configure ipv6 nd state not-present rate-limit [<100-86400000>] no

Supplemental

Information

To reset, use the no option.

Parameters

<100-86400000>

Minimum time, in seconds, between ICMPs.

Default Chapter7
