Arris C4C - Show Cable Channel-Sets

To Next Page

To Previous Page

Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show cable channel-sets

Purpose

Displays the status of the cable channel sets for the specified cable-mac.

Default Access Level

Command Syntax

show cable channel-sets [<ds | us>] [cable-mac <int>] [channel-set-id <word>] [full]

Supplemental

Information

N/A

Parameters

Upstream (us) or Downstream (ds) direction only

[cable-mac <int>]

Static bonding group identifier. Valid range is 1-65535.

[channel-set-id

<word>]

The channel set ID

[full]

Displays all configuration values, including single channel sets.
