Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure operation mode

Purpose

Configures the Upper Level Protocol (ULP) operation mode.

Default Access Level

Command Syntax

configure operation mode <operation mode>

configure operation mode <operation mode> no

Supplemental Information

To disable the ULP operation mode, use the no option.
