The C4/c CMTS continues to support distribute-lists for filtering RIP IP prefixes that are redistributed into OSPF. The
CadPolicyAclTable MIB must be used when creating an ACL. The ACL defined must be a standard ACL (range 0-99).
Execution of this command will create an entry in the cadDistListOutTable. If the corresponding route redistribution
command has already been executed, then each entry in the ACL table will create an entry in the rtmRedistTable.
There must also be a "wildcard" match entry in the rtmRedistTable for either the "permit_all" or "deny_all" ACL case, with
the rtmRedistFlag set to AMB_TRUE or AMB_FALSE.
Note: The priority (rtmRedistPriority) must be set to a value greater than (implies lower priority) the more specific
matches.
For example:
configure access-list 10 deny 130.10.0.0 0.0.255.255
configure access-list 10 permit 0.0.0.0 255.255.255.255
configure router ospf [vrf <VRF>] distribute-list 10 out rip
Filtering Redistributed BGP Routes
To filter redistributed BGP routes, use the following commands:
configure router bgp [no] distribute-list ACL-NUM out static
configure router bgp [no] distribute-list ACL-NUM out connected
configure router bgp [no] distribute-list ACL-NUM out rip
configure router bgp [no] distribute-list ACL-NUM out ospf
configure router bgp [no] distribute-list ACL-NUM out isis
Although not specifically associated with route redistribution, the C4/c CMTS continues to support filtering IP routes based
on an egress interface. The existing CadPolicyAclTable MIB must be used when creating an ACL. The ACL defined must be a
standard ACL (range 0-99).
Execution of this command will create an entry in the cadDistListOutTable. If the corresponding route redistribution
command has already been executed, then each entry in the ACL table will create an entry in the rtmRedistTable.
There must also be a "wildcard" match entry in the rtmRedistTable for either the "permit_all" or "deny_all" ACL case, with
the rtmRedistFlag set to AMB_TRUE or AMB_FALSE.
Note: The priority (rtmRedistPriority) must be set to a value greater than (implies lower priority) the more specific
matches.
