Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface cable-mac * cable energy-mgmt low-power-1x1

Purpose

Configures Energy Management 1x1 Mode on the CMTS.

Default Access Level

Command Syntax

configure interface cable-mac <mac> cable energy-mgmt low-power-1x1

configure interface cable-mac <mac> cable energy-mgmt low-power-1x1 no

Supplemental

Information

To disable, use the no option.
