Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure l2vpn cable-mac

Purpose

Configures all cable MAC interfaces participating in the L2VPN service.

Default Access Level

Command Syntax

configure l2vpn cable-mac {<mac_id> |all}

configure l2vpn cable-mac {<mac_id> |all} no

Supplemental

Information

CMs that attempt to register as L2VPN in non-participating cable-mac interfaces are rejected.

Note: Only designated cable MAC interfaces are able to host L2VPN CMs.

To remove the cable MAC interfaces participating in the L2VPN service, use the no version.

Parameters

<mac_id>

ID of the MAC interface. Range is 0 - 415.

all

All cable-mac interfaces.

Default Chapter7
