Chapter 46: Command Line Descriptions
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 2323
configure route-map-policy * set ip dscp
This command is used to overwrite the six Differentiated Services Codepoint (DSCP) bits in the TOS byte with <value> where the
value is one of the reserved keywords listed below or a numeric value of 0-63.
configure route-map-policy <word> set ip dscp <value>
configure route-map-policy <word> set ip dscp [<value>] no
Only one set ip dscp command for each route-map with a unique sequence number in the system will be allowed. If multiple set ip
dscp commands are executed, they will simply replace the previous one. This behavior is consistent with the set ip tos and set
ip precedence commands.
To remove a previously set ip dscp value, use the no option.
Parameters
