Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show tacacs

Purpose

Displays all configured TACACS+ server groups, the members of each group, and the operational parameters of each group

member.

Default Access Level

Command Syntax

show tacacs [detail]

Supplemental

Information

If the detail keyword is added, then utilization and performance measurements are also displayed for each TACACS+ server.

Parameters

[detail]

Show TACACS+ information in detail
