Chapter 46: Command Line Descriptions
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 1770
configure interface gigabitethernet * ip pim sparse-mode-ssm
Purpose
Enables PIM sparse-mode SSM operation on a network-side interface.
Default Access Level
15
Command Syntax
configure interface gigabitethernet <slot>/<port>[.<0-254>] ip pim sparse-mode-ssm [passive]
configure interface gigabitethernet <slot>/<port>[.<0-254>] ip pim sparse-mode-ssm [passive] no
Supplemental
Information
To disable, use the no option.
Parameters
<slot>/<port>[.<0-
254>]
RCM slot number/gigabitEthernet port number[.subinterface number].
Valid range for the C4 CMTS is <17-18>/<0-9>[.<0-254>]
Valid range for the C4c CMTS is <17>/<0-9>[.<0-254>]
[passive]
Runs PIM passively (no sent/rcvd messages)
