Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure reset cable-modem * slot

Purpose

Resets or deletes cable modems on a specified slot.

Default Access Level

Command Syntax

configure reset cable-modem [delete] [bonded] [offline] [reject] [vendor <word>] [oui <word>] [all]

[bonded-impaired] slot <word>

Supplemental

Information

N/A

Parameters

[delete]

Deletes the requested CM(s)

[bonded]

Filters on bonded CMs

[offline]

Filters on offline CMs

[reject]

Filters on rejected CMs

[vendor <word>]

Filters on CMs for a specified vendor

[oui <word>]

Filters on CMs with specified OUI (most significant 3 bytes of Vendor MAC address)

[all]

Filters on all CMs

[bonded-impaired]

Filters on bonded CMs that are not functioning at full capacity

<word>

CAM slot. <0-5, 8-13>
