Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show interface cable-downstream * cable ip-video

Purpose

Displays the multicast packets transmitted and IP video flows created per hour

Default Access Level

Command Syntax

show interface cable-downstream <slot[/ch]> cable ip-video [<drops | multicast |unicast | all>]

Supplemental

Information

N/A

Parameters

<slot[/ch]>

Slot or slot and optional channel.

drops

Displays packets dropped per hour.

multicast

Displays multicast packets transmitted and IP video flows created per hour.

unicast

Displays unicast packets transmitted and IP video flows created per hour.

all

Displays all the information above
