configure interface link-aggregate * ip pim message-holdtime

Purpose

Configures the PIM router message (prune/join) hold time.

Default Access Level

Supplemental

Information

To reset the hold time, use the no option.

Parameters

<0-9[.0-254]>

LAG identifier <lag[sub interface]>

<1-65535>

Prune/join message holdtime in seconds
