configure logging debug

Purpose

Enables notification for the specified debug facility. If slot number is specified, then notification will be enabled only for that slot.

Default Access Level

Command Syntax

configure logging debug <facility> [<class>] [<subclass>] [slot <slot-num>] [filter {cmMac | ifMac |

subIp}] [filter_data <filter_data_value>]

configure logging debug <facility> [<class>] [<subclass>] [slot <slot-num>] [filter {cmMac | ifMac |

subIp}] [filter_data <filter_data_value>] no
