Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure audit sequence * card * run-now

Purpose

Enables audit sequences on specified cards to run immediately.

Default Access Level

Command Syntax

configure audit sequence [<name>] card [<slot>] run-now

Supplemental

Information

If no audit sequence or slot number is specified, then all cards in service will be enabled to run immediately.

Parameters

[<name>]

Audit Sequence Name. Valid names are:

AuditCMMac

AuditCMQos

IpFilter

AuditCMBpi

CAMSparing

CAMManager

PersistentStore

PacketCableGates

[<slot>]

Audit card slot number. Valid range for the C4 CMTS is 0-20; valid range for the C4c CMTS is 10-15, 17, and 19.
